Features
TURBOVENT™ DRYER TECHNOLOGY
A high-speed blower wheel optimizes performance in long vents, while high airflow reduces drying times for a wide variety of loads, increasing efficiency and turns over the life of the machine.
DURACORE DRIVE SYSTEM
Designed and tested to run 15,000 cycles.* A watertight, flexible triple-lip seal with a garter spring helps keep moisture away from the shaft, protecting our premium bearings – while our proven, durable shaft sleeve is designed to reduce shaft wear. These components, along with a die-cast trunnion, result in more turns over the life of the washer, helping to boost your bottom line.
*Based on 11-lb. load, 34 min. timed cycle, Heavy Soil
INTELLIGENT CONTROLS WITH M-SERIES TECHNOLOGY
Intelligent Controls with M-Series Technology help owners increase profitability. These enhanced controls allow customized setup – each cycle and option can be priced individually or programmed for time-of-day pricing, maximizing revenue opportunity.
ADVANCED SPIN TECHNOLOGY
Featuring a 6-point suspension system, accelerometer, Progressive Spin Logic, and an optimized pump routine, Advanced Spin Technology helps deliver accurate cycle times and optimal performance for all load types.
Specifications
General
Type
Coin
Coin Box Included
No
G-Force
300
Washer Capacity (DOE)
3.1 cu. ft.
Dryer Capacity
6.7 cu. ft.
Color
White
Fuel Type
Gas
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Features
Technologies
• Intelligent Controls with M-Series Technology
• Maytag Connect 360º Compatible
• Duracore Drive System
• Advanced Spin Technology
• PowerWash® Cycle
• TurboVent® Dryer Technology
• Maytag Connect 360º Compatible
• Duracore Drive System
• Advanced Spin Technology
• PowerWash® Cycle
• TurboVent® Dryer Technology
Energy Star Certified
Yes
Washer Information
• Operating Pressure – psi (bar): 20 – 100 (1 – 8)
• Inlet Hose Length — ft. (m): 4 (1.22)
• Drain Hose Length — ft. (m): 6 (1.83)
• Average Total Water Usage Per Cycle — gallons (liters): 10.71 (40.50)
• Average Hot Water Usage, Warm Water Cycle — gallons (liters): .71 (2.69)
• Average Hot Water Usage, Hot Water Cycle — gallons (liters): 2.71 (10.26)
• Motor Size - HP (kw): .09 (.07)
• ADA Compliant
• Integrated Water Factor (IWF): 3.5
• Modified Energy Factor (MEF): 2.2
• Inlet Hose Length — ft. (m): 4 (1.22)
• Drain Hose Length — ft. (m): 6 (1.83)
• Average Total Water Usage Per Cycle — gallons (liters): 10.71 (40.50)
• Average Hot Water Usage, Warm Water Cycle — gallons (liters): .71 (2.69)
• Average Hot Water Usage, Hot Water Cycle — gallons (liters): 2.71 (10.26)
• Motor Size - HP (kw): .09 (.07)
• ADA Compliant
• Integrated Water Factor (IWF): 3.5
• Modified Energy Factor (MEF): 2.2
Dryer Information
• AirFlow (CFM): 230 (6.5)
• Motor Size - HP (kw): 33 (.25)
• Dryer Exhaust Duct Dismeter - in (mm): 4 (100)
• Motor Size - HP (kw): 33 (.25)
• Dryer Exhaust Duct Dismeter - in (mm): 4 (100)
Accessories
Optional
Coin Kit
Dimensions
Class Width
27"
Width
27 inch(es) / 68.58 cm
Height
74 inch(es) / 187.96 cm
Depth
29.5 inch(es) / 74.93 cm
Weight
372.01 lb(s) / 168.74 kg
Shipping Dimensions
Width
29.25 inch(es) / 74.3 cm
Height
75.75 inch(es) / 192.41 cm
Depth
34 inch(es) / 86.36 cm
Weight
383.01 lb(s) / 173.73 kg
Warranty
Warranty
5 Years Parts
UPC
UPC#
883049439549
