Documents
Features
SPEEDBOOST®
Sometimes you don't want to wait for a pot of water to boil. The SpeedBoost® function on Bosch induction cooktops adds even more power to speed up the cooking process.
RESTART
If you turn off the cooktop it saves the last selected setting for a short time. If the cooktop is switched of within a short time again the former settings are still available.
PRECISESELECT®
Juggling multiple pots and pans on different power levels can be confusing and frustrating. With PreciseSelect®, an intuitively designed control panel allows you to select the cooking zones and set the specific power level you want – quickly and easily.
INDUCTION TECHNOLOGY
Induction technology directly heats your pots and pans instead of the cooktop itself for faster cooking and precise results.
Specifications
General
Series Name
500 Series
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Heating element (W): 1.4 kW
• Heating element (W) : 2.2 kW
• Heating element (W) : 2.2 kW
Burner/Element Size
• Heating element (in): 6''
• Heating element (in): 9''
• Heating element (in): 9''
Elements
Smoothtop
Features
Technologies
• Induction Technology
• SpeedBoost®
• PreciseSelect® Control Panel
• PotSense
• SpeedBoost®
• PreciseSelect® Control Panel
• PotSense
Control Lock
Yes
Digital Display
Yes
Additional Information
• 17 power levels for each cooking zone
• Large 11" cooking zone offers 3,700W of power for precise results
• SpeedBoost® - adds even more power to speed up the cooking process
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Use the Kitchen Timer to Measure Cooking Time or as a Reminder
• Digital 2-Stage Residual Heat Indicator for Each Cooking Zone
• Wipe Protection - Quickly Pauses Settings to Clean as You Go
• Large 11" cooking zone offers 3,700W of power for precise results
• SpeedBoost® - adds even more power to speed up the cooking process
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Use the Kitchen Timer to Measure Cooking Time or as a Reminder
• Digital 2-Stage Residual Heat Indicator for Each Cooking Zone
• Wipe Protection - Quickly Pauses Settings to Clean as You Go
Electrical Information
Information
• 6240 W
• 30 A
• 60 Hz
• 208 -240 V
• 30 A
• 60 Hz
• 208 -240 V
Certifications and Approvals
Information
Dekra Mark C+US
FCC
Dimensions
Class Width
30"
Width
31.02 inch(es) / 78.8 cm
Height
4.13 inch(es) / 10.5 cm
Depth
21.26 inch(es) / 54.0 cm
Weight
39.99 lb(s) / 18.14 kg
Additional Dimensions
• Required cutout size (HxWxD): 3 3/4"x 28 7/8" x 20"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
Shipping Dimensions
Width
36.62 inch(es) / 93.02 cm
Height
7.06 inch(es) / 17.93 cm
Depth
23.65 inch(es) / 60.08 cm
Weight
47.99 lb(s) / 21.77 kg
UPC
UPC#
825225961451
