Zephyr 48-inch Monsoon Connect Built-In Hood Insert AK9446BS

ZephyrModel Number: AK9446BS
Monsoon Connect is unique in the marketplace. Optional dual 1300-CFM PowerWave™ blowers and stainless steel baffle filters make for a... Monsoon Connect is unique in the marketplace. Optional dual 1300-CFM PowerWave™ blowers and stainless steel baffle filters make for a powerful, performance-driven range hood insert that is easy to clean. A wireless remote-control option and Zephyr Connect, Zephyr's most advanced operation system, make the Monsoon Connect the most quiet and energy-efficient, one-piece liner available today. View more
Save $270.00 Price:
$2,659.00 $2,929.00
Warranty Products

Please select a warranty option

Available Services

Delivery Will Be Calculated at Checkout

Find a store

Since 1975

We have been serving our local communities for 48 years.

#ShopLocal

Two Locations to Serve You

From Chilliwack to Pemberton, we cover over 300kms.

Service & Installation

Avoid dealing with the manufacturer’s 1-800-#’s.

Have a service issue? We have a in house service team!

You may also like

Features Specifications Documents
Documents
Installation Guide
Owners Manual
Product Specifications
Warranty Details
Dimensions Sheet
Additional Documents
Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
ACT™ CONTROL TECHNOLOGY
POWERWAVE™ 3-PHASE BLOWER TECHNOLOGY
Delivers best-in-class performance with unparalleled quiet operation. It provides more power while minimizing noise and improving efficiency.
ZEPHYR CONNECT APP
Zephyr Connect App allows you to control your range hood from anywhere using your mobile device. It includes real time diagnostics and provides important product information. All you need is a WiFi connection with access to the internet. It seamlessly integrates with your smart devices such as Amazon Alexa or Google Home smart speaker for voice activation. Available to download from Google Play or the App Store.
Specifications
General
Series Name
• Monsoon Connect
• Core Collection
Blower Included
Yes
Airflow
700 CFM
Style
Custom Insert
Color
Stainless Steel
Installation
Built-In
Features
Wi-Fi
Yes
Technologies
• Airflow Control Technology™ (ACT™)
• PowerWave™ blower
• LumiLight
• Zephyr+ with Zephyr Connect App
• Alexa and Google Home Compatible
Ducting Information
• Vertical or Horizontal Single Internal Blower: 8" Round
• Vertical Dual Internal Blower: 10" Round
Speeds
6
Additional Information
• Blower CFM (Min. - Max.): 200 - 700
• Optional Dual Blower (Min. - Max.): 300 - 1,300
• Sones (Min. - Max.): 0.8 - 6
• Controls: Proximity Touch
• Auto Delay-Off
• CleanAir Function
• Lighting: LumiLight LED, 6W x4
• Tri-Level Lighting
• Filters: Pro Baffle x3
• Removable Grease Tray
Electrical Information
Information
• AC POWER (Single Blower): 120V, 60Hz at Max. 5A
• AC POWER (Dual Blower): 120V, 60Hz at Max. 8A
Accessories
Optional
• Wireless Remote Control: 14000005
• Dual Internal Blower: PBD-1300B
• Make-Up Air Kit (Single Blower): MUA008A
• Make-Up Air Kit (Dual Blower): MUA010A
Dimensions
Class Width
48"
Width
46.37 inch(es) / 117.79 cm
Height
12 inch(es) / 30.48 cm
Depth
19.25 inch(es) / 48.9 cm
Additional Dimensions
Mounting Height Range: 24" - 36"
Warranty
Warranty
• 1-Year for labor
• 3-Year for parts
