Features
MECHANICAL SLIDE CONTROL
Mechanical slide control
ALUMINUM MESH FILTERS
The aluminum mesh filters installed by the factory are intended to filter out residue and grease from cooking. They need not be replaced on a regular basis but are required to be kept clean.
Specifications
General
Series Name
• Tornado Mini
• Core Collection
• Core Collection
Blower Included
Yes
Airflow
400 CFM
Style
Custom Insert
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Built-In
Features
Ducting Information
Vertical Internal Blower: 6" Round
Speeds
• Speed Levels: 3
• Blower CFM (Min. - Max.): 210 - 400
• Sones (Min. - Max.): 2 - 5
• Blower CFM (Min. - Max.): 210 - 400
• Sones (Min. - Max.): 2 - 5
Additional Information
• Controls: Mechanical Slide
• Lighting: LumiLight LED, 6W x2
• Dual-Level Lighting
• Filters: Aluminum Mesh x1
• Recirculating Option
• Lighting: LumiLight LED, 6W x2
• Dual-Level Lighting
• Filters: Aluminum Mesh x1
• Recirculating Option
Electrical Information
Information
120V, 60Hz at Max. 3A
Certifications and Approvals
Information
cULus
Accessories
Optional
• 30" Liner (17-1/2" - 20-1/2" Depth): AK0840AS
• 36" Liner (17-1/2" - 20-1/2" Depth): AK0846AS
• Recirculating Kit: ZRC-8400A
• 36" Liner (17-1/2" - 20-1/2" Depth): AK0846AS
• Recirculating Kit: ZRC-8400A
Dimensions
Class Width
21"
Width
20.56 inch(es) / 52.23 cm
Height
10.87 inch(es) / 27.62 cm
Depth
11 inch(es) / 27.94 cm
Additional Dimensions
Mounting Height Range:
• Electrical Cooktop: 20" - 36"
• Gas Cooktop: 24" - 36"
• Electrical Cooktop: 20" - 36"
• Gas Cooktop: 24" - 36"
Warranty
Warranty
• 3-Year limited on parts
• 1-Year limited for labor
• 1-Year limited for labor
