Zephyr 36-inch Apex Series Wall Mount Hood Shell DAP-M90AMBX

ZephyrModel Number: DAPM90AMBX
Exceptional style, plus the power and performance you’d expect from Zephyr. Featuring Perimeter Aspiration System, easy Capacitive Touch Controls and... Exceptional style, plus the power and performance you’d expect from Zephyr. Featuring Perimeter Aspiration System, easy Capacitive Touch Controls and a recirculating option, the Apex Wall is a hood for today, tomorrow, and beyond. Also includes optional duct cover and remote control. Blower sold separately. View more
Save $270.00 Price:
$2,599.00 $2,869.00
Warranty Products

Please select a warranty option

Available Services

Delivery Will Be Calculated at Checkout

Find a store

Since 1975

We have been serving our local communities for 48 years.

#ShopLocal

Two Locations to Serve You

From Chilliwack to Pemberton, we cover over 300kms.

Service & Installation

Avoid dealing with the manufacturer’s 1-800-#’s.

Have a service issue? We have a in house service team!

You may also like

Features Specifications Documents
Documents
Installation Guide
Owners Manual
Product Specifications
Dimensions Sheet
Features
CLEAN AIR
Clean Air is a feature that turns the blower on every 4 hours for 10 minutes to remove stagnant air in the kitchen. This feature is disabled by default and must be enabled by the user.
DELAY OFF
This feature is used for programmed shut down of blowers 15 minutes after the function is activated. Press once, a dot flashes in the lower right side of display indicating the function is on. The blowers will shut down after 15 minutes.
Specifications
General
Series Name
Apex
Blower Included
No
Style
Standard
Color
Black
Manufacturer Color
Matte Black
Installation
Wall Mount
Features
Technologies
Perimeter Aspiration System
Ducting Information
• Vertical Single Internal Blower 6" Round
• Vertical In-Line/External Blower 10" to 8" Round
• Horizontal Single Internal Blower 6" Round
• Horizontal In-Line/External Blower 10" to 8" Round
Speeds
3 Speeds
Additional Information
• Capacitive Touch Controls
• Auto Delay-Off
• CleanAir Function
• Lighting LED, 5W x2
• Tri-Level Lighting
• Filters Aluminum Mesh x2
• Recirculating (Not compatible with optional duct cove)
Certifications and Approvals
Information
ADA with Remote Option
Accessories
Optional
• Internal Blower (CBI-290C) 200-290 CFM, 1.4-3 sones
• Internal Blower (CBI-600A) 240-600 CFM, 1.8-6 sones
• In-Line Blower (PBN-1000A) 500-1,000 CFM, sones NA
• External Blower (CBE-1000) 500-1,000 CFM, sones NA
• Recirculating Kit ZRC-00AP
• Remote Control 14000010
• Duct Cover - Matte Black Z1C-00MEMB
• Duct Cover - Stainless Steel Z1C-00MESS
• Make-Up Air Kit MUA006A (600 CFM), MUA008A (1,000 CFM)
Dimensions
Class Width
36"
Width
35.37 inch(es) / 89.85 cm
Height
19.75 inch(es) / 50.17 cm
Depth
19.81 inch(es) / 50.32 cm
Warranty
Warranty
2 Year Parts, 1 Year Labor
