Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Vapor Clean
Cooktop
Burners/Elements
6
Burners/Elements Output
• Left - 5.3 kW - 22000 BTU
• Rear centre - 3.5 kW - 15000 BTU
• Front centre - 1.31 kW - 5000 BTU
• Central - 1.40 kW
• Rear right - 3.5 kW
• Front right - 2.34 kW - 8000 BTU
• Rear centre - 3.5 kW - 15000 BTU
• Front centre - 1.31 kW - 5000 BTU
• Central - 1.40 kW
• Rear right - 3.5 kW
• Front right - 2.34 kW - 8000 BTU
Burners
Sealed
Other
Griddle
Oven
Capacity (cu. ft.)
• Total Capacity: 7.54 cu. ft.
• Large Oven: 4.45 cu. ft.
• Small Oven: 3.9 cu. ft.
• Large Oven: 4.45 cu. ft.
• Small Oven: 3.9 cu. ft.
Number of Ovens
Double
Programs
• Static
• Fan assisted Circulaire
• Small grill
• Large grill
• Fan grill (large)
• Base
• Fan assisted bottom Pizza
• Defrost by time
• Fan assisted Circulaire
• Small grill
• Large grill
• Fan grill (large)
• Base
• Fan assisted bottom Pizza
• Defrost by time
Features
Technologies
True Convection Technology
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• The best cooking performances guaranteed by ventilated circular flow. - True-convection
• Easy oven cleaning thanks to special pyrolytic enamel
• Easy and intuitive timer setting with a single touch
• The best cooking performance at the highest energy efficiency
• The oven has two fans equipped with two circular heating elements allowing cooking with rotating heat
• New cooling system with tangential fan and airflow from the door to the splashback
• The door is equipped with a specific system for silent closing
• Main Oven:
• No. of lights: 2
• Fan number: 2
• Cavity material: Ever Clean enamel
• No. of shelves: 5
• Type of shelves Metal racks
• Light type Halogen
• Light Power: 40 W
• Cooking time setting: Start and Stop
• Light when oven door is open
• Removable door
• Total no. of door glasses: 3
• Safety Thermostat
• Cooling system: Tangential
• Lower heating element power: 1700 W
• Upper heating element Power: 1200 W
• Grill element: 1700 W
• Large grill - Power: 2900 W
• Circular heating element Power: 1500 W
• Soft Close system
• Second Oven:
• Fan number: 1
• Cavity material: Ever Clean enamel
• No. of shelves: 5
• Type of shelves Metal racks
• No. of lights: 2
• Light type: Halogen
• Light Power: 40 W
• Light when oven door is open
• Removable door
• No. total door glasses: 3
• Safety Thermostat Yes
• Cooling system Tangential
• Lower heating element power: 750 W
• Large grill Power: 2050 W
• Circular heating element Power: 1500 W
• Soft Close system
• Easy oven cleaning thanks to special pyrolytic enamel
• Easy and intuitive timer setting with a single touch
• The best cooking performance at the highest energy efficiency
• The oven has two fans equipped with two circular heating elements allowing cooking with rotating heat
• New cooling system with tangential fan and airflow from the door to the splashback
• The door is equipped with a specific system for silent closing
• Main Oven:
• No. of lights: 2
• Fan number: 2
• Cavity material: Ever Clean enamel
• No. of shelves: 5
• Type of shelves Metal racks
• Light type Halogen
• Light Power: 40 W
• Cooking time setting: Start and Stop
• Light when oven door is open
• Removable door
• Total no. of door glasses: 3
• Safety Thermostat
• Cooling system: Tangential
• Lower heating element power: 1700 W
• Upper heating element Power: 1200 W
• Grill element: 1700 W
• Large grill - Power: 2900 W
• Circular heating element Power: 1500 W
• Soft Close system
• Second Oven:
• Fan number: 1
• Cavity material: Ever Clean enamel
• No. of shelves: 5
• Type of shelves Metal racks
• No. of lights: 2
• Light type: Halogen
• Light Power: 40 W
• Light when oven door is open
• Removable door
• No. total door glasses: 3
• Safety Thermostat Yes
• Cooling system Tangential
• Lower heating element power: 750 W
• Large grill Power: 2050 W
• Circular heating element Power: 1500 W
• Soft Close system
Drawer Features
Storage
Yes
Electrical Information
Information
• Plug: (B) NEMA 14-50P
• Electrical connection rating: 8500 W
• Current: 35 A
• Circuit breaker: 40 A
• Voltage: 208/240 V
• 60 Hz
• Type of electric cable installed: Yes, Double phase
• Power supply cable length: 47 1/4"
• Electrical connection rating: 8500 W
• Current: 35 A
• Circuit breaker: 40 A
• Voltage: 208/240 V
• 60 Hz
• Type of electric cable installed: Yes, Double phase
• Power supply cable length: 47 1/4"
Accessories
Included
• Cast iron wok support: 1
• TOP Oven grid with back stop: 4
• Telescopic Guide rails, total Extraction: 2
• TOP Oven grid with back stop: 4
• Telescopic Guide rails, total Extraction: 2
Dimensions
Class Width
48"
Width
47.24 inch(es) / 120 cm
Height
35.43 inch(es) / 90 cm
Depth (Without Handles)
23.62 inch(es) / 60 cm
Weight
339 lb(s) / 153.77 kg
Shipping Dimensions
Width
50.39 inch(es) / 128 cm
Height
41.73 inch(es) / 106 cm
Depth
28.94 inch(es) / 73.5 cm
Weight
412 lb(s) / 186.88 kg
Warranty
Warranty
2 Years
