Features
CONTROL LOCK/CHILD SAFETY
This system will allow you to prevent children from touching the burners or changing the settings.
Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Front left: 1200 W
• Rear left: 1800 W
• Rear right: 750 - 1800 W
• Front right: 1200 W
• Rear left: 1800 W
• Rear right: 750 - 1800 W
• Front right: 1200 W
Burner/Element Size
• Front left: 5.83"
• Rear left: 7.24"
• Rear right: 4.88" - 7.24"
• Front right: 5.83"
• Rear left: 7.24"
• Rear right: 4.88" - 7.24"
• Front right: 5.83"
Elements
Smoothtop
Surface Features
Ceramic glass cooktop with beveled edges
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Ultra-low profile
• Touch controls
• Booster cook
• 9 Power levels
• End cooking timer
• End of cooking alarm
• Limited power consumption mode
• Showroom demo option
• Controls lock / Child safety
• Touch controls
• Booster cook
• 9 Power levels
• End cooking timer
• End of cooking alarm
• Limited power consumption mode
• Showroom demo option
• Controls lock / Child safety
Electrical Information
Information
• Electrical connection rating: 6000 W
• Voltage: 240 V
• Voltage 2: 208 V
• Frequency: 60 Hz
• Cord type: Single phase
• Voltage: 240 V
• Voltage 2: 208 V
• Frequency: 60 Hz
• Cord type: Single phase
Accessories
Included
Scraper
Dimensions
Class Width
24"
Width
24 inch(es) / 60.96 cm
Height
3.25 inch(es) / 8.26 cm
Depth
20.94 inch(es) / 53.18 cm
Additional Dimensions
Lenght of electrical supply cord: 47.25"
Warranty
Warranty
1-Year parts and labor
