Features
PRECISION KNOBS
With embedded sapphire glass illuminate each knob making it easy to view and select heat settings
DUAL-FLAME STACKED BURNERS
Provide complete 140F simmer-to-rapid-boil flexibility on all burners; the burners are sealed to the cooktop for easy cleaning
TRI-RING BURNER
Versatile burner creates 20,000 BTUs of intense heat, perfect for searing, frying and sautéing
BRASS BURNERS ACCENTS
For the ultimate in elegant styling.
ELECTRONIC KITCHEN TIMER
Built in to the cooktop for meal preparation
REMOTE CONNECTIVITY VIA WIFI
Allows you to wirelessly control gas cooktop functions from your smartphone
BLUETOOTH CONNECTIVITY
Bluetooth technology pairs your Monogram gas cooktop and hood for proper cooking ventilation
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Natural Gas
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Left front: 10,000 BTU dual brass center
• Left rear: 10,000 BTU dual brass center
• Right front: 12,000 BTU dual brass center
• Right rear: 10,000 BTU dual brass center
• Center: 20,000 BTU tri-ring brass cap
• Left rear: 10,000 BTU dual brass center
• Right front: 12,000 BTU dual brass center
• Right rear: 10,000 BTU dual brass center
• Center: 20,000 BTU tri-ring brass cap
Burners
Sealed
Surface Features
Cast-iron, porcelainized continuous grates
Features
Technologies
• Bluetooth connectivity
• Remote connectivity
• Remote connectivity
Wi-Fi
Yes
Clock
Yes
Control Lock
Yes
Digital Display
Yes
Downdraft Ventilation
No
Additional Information
• Dual flame stacked burners
• Glass touch controls
• Control lock capability
• Kitchen timer
• Stainless steel control knobs
• Burner indicator light in knobs
• Built-in WiFi connect
• Glass touch controls
• Control lock capability
• Kitchen timer
• Stainless steel control knobs
• Burner indicator light in knobs
• Built-in WiFi connect
Electrical Information
Information
• 120V
• 60Hz
• 5A
• 60Hz
• 5A
Certifications and Approvals
ADA Compliant
Yes
Accessories
Included
• Griddle: JXGRIDL236
• LP conversion kit
• LP conversion kit
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
7.87 inch(es) / 20.00 cm
Depth
21 inch(es) / 53.34 cm
Weight
59 lb(s) / 26.76 kg
Additional Dimensions
Cutout dimensions (WxD): 33-7/8" x 19-1/8"
Shipping Dimensions
Width
27.3 inch(es) / 69.34 cm
Height
12.3 inch(es) / 31.24 cm
Depth
39 inch(es) / 99.06 cm
Weight
64.99 lb(s) / 29.48 kg
Warranty
Warranty
Limited 2-year warranty on parts and labor for entire appliance
UPC
UPC#
084691826699
