Features
FULLY FLUSH INSTALLATION WITH HIDDEN HINGES
Provides a built-in look within a standard 24" base cabinet, so your style stands out, not the appliance. Hidden hinges allow the beverage center door to sit flush with surrounding cabinet fronts when closed yet easily swing open a full 90 degrees.
TWO TEMPERATURE-CONTROLLED ZONES (FOR BEVERAGE CELLAR)
Allows for two independent temperature zones to chill beverages, hors d'oeuvres and wine bottles in their optimal climate. The top zone adjusts temperature from 33-40°F, while the lower zone can be adjusted from 42-64°F.
TEMPERATURE MONITORING SYSTEM
Uses sensors to monitor temperatures inside the beverage center for added peace of mind. If the system detects temperatures above 70°F for more than 4 hours, an over-temp alarm and indicator light will alert you that service is needed.
MOTION-ACTIVATED LED LIGHTING
Turns on inside as you approach, so you can see what's inside without opening the door. Lights will gradually dim and turn off when no longer needed.
SATINGLIDE® METAL-FRONT RACKS
Provides smooth movement even on fully loaded racks. The metal front gives the racks a bold, high-end design.
PRINTSHIELD™ FINISH
Resists smudges while enhancing the overall look of the refrigerator. This new feature for KitchenAid® takes the worry out of keeping a working kitchen beautiful.
UV-PROTECTED THERMAL GLASS DOOR
Helps prevent sunlight from prematurely aging wine.
GLASS SHELF/SHELVES WITH METAL TRIM
Are a worry free way to store and locate your favorite beverages and other food items. These metal front shelves can easily be cleaned and stop spills from spreading in the refrigerator.
DOOR ALARM
Automatically alerts you when the door has been left OPEN before items inside rise above their ideal temperature. The alarm sounds after fives minutes and goes off every two minutes until the door has been closed or the controls have been pressed.
BACKLIT TOUCH CONTROLS
Located on the divider between the two temperature zones make it easy to choose settings for what you're storing. The lighted control panel displays current temperatures for each zone and other status alerts.
AUTOMATIC DEFROST
Cycles automatically to help reduce frost build-up, freeing you from having to regularly empty the appliance and manually defrost.
MAX COOL
Keeps the refrigerator and freezer internal temperatures cold during times of excessive usage.
Specifications
General
Type
Beverage Center
Installation
Built-In
Size
Compact
Color
Black Stainless Steel
Manufacturer Color
Black Stainless
Cabinet Color
Black
Temperature Zones
2
Temperature Settings
• Upper Temperature Range: 33F to 40F
• Lower Temperature Range: 42F to 64F
• Lower Temperature Range: 42F to 64F
Hinge Side
Left
Capacity
Total Capacity
4.89 cu. ft.
Bottles
14
Wine Racks
2
Features
Technologies
• SatinGlide® Full-Extension Metal-Front Racks
• PrintShield™ Finish
• PrintShield™ Finish
Digital Temperature Display
Yes
Glass Door
Yes
Reversible Door
No
Additional Information
• Auto Defrost
• Control Type: Light-Guided Capacitive Touch
• Cooling On/Off
• Door Ajar/Open Alarm
• Control Lockout
• LED Interior Light
• Rack Front Material: Stainless Steel
• 1 Fixed Full-Depth Shelf
• 1 Fixed Half-Depth Shelf
• Handle Type: Reach-Through Handle
• Control Type: Light-Guided Capacitive Touch
• Cooling On/Off
• Door Ajar/Open Alarm
• Control Lockout
• LED Interior Light
• Rack Front Material: Stainless Steel
• 1 Fixed Full-Depth Shelf
• 1 Fixed Half-Depth Shelf
• Handle Type: Reach-Through Handle
Electrical Information
Information
• 115V
• 15A
• 15A
Certifications and Approvals
Energy Star Certified
No
Sabbath
Yes
Dimensions
Class Width
24"
Width
23.87 inch(es) / 60.64 cm
Height
34.37 inch(es) / 87.31 cm
Depth
26.44 inch(es) / 67.15 cm
Weight
109.11 lb(s) / 49.49 kg
Additional Dimensions
• Cutout Depth: 24"
• Cutout Height: 34 1/2"
• Cutout Width: 24"
• Depth With Door Open 90 Degree: 48"
• Height To Top Of Cabinet: 34 5/32"
• Cutout Height: 34 1/2"
• Cutout Width: 24"
• Depth With Door Open 90 Degree: 48"
• Height To Top Of Cabinet: 34 5/32"
Shipping Dimensions
Width
25.75 inch(es) / 65.41 cm
Height
35.94 inch(es) / 91.28 cm
Depth
29.69 inch(es) / 75.41 cm
Weight
120 lb(s) / 54.43 kg
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
883049592916
