Features
SPACEWISE® BRIDGE ELEMENT
A flexible element lets you combine two elements into one to fit larger cookware.
POWERPLUS INDUCTION TECHNOLOGY
PowerPlus™ Induction Technology boils water in less than 2 minutes so you can shave time off of cooking dinner every day.
GAS BENEFITS, WITHOUT THE REMODEL
PowerPlus™ Induction Cooktop offers the the speed, control and consistency of gas, without requiring the converting of your kitchen from electric to gas.
CONSISTENT RESULTS
Even heat eliminates hot spots and delivers consistent results for creating delicious, evenly cooked foods like steaks and omelettes.
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric Induction
Cooktop
Burners/Elements
5
Power Output
• Right Front: 2,500/3,800W
• Right Rear: 1,450/2,000W
• Left Bridge: 1,800/2,600W
• Left Rear: 1,800/2,600W
• Center: 2,300/3,200W
• Right Rear: 1,450/2,000W
• Left Bridge: 1,800/2,600W
• Left Rear: 1,800/2,600W
• Center: 2,300/3,200W
Burner/Element Size
• Right Front: 10"
• Right Rear: 6"
• Left Bridge: 7"
• Left Rear: 7"
• Center: 8"
• Right Rear: 6"
• Left Bridge: 7"
• Left Rear: 7"
• Center: 8"
Elements
Smoothtop
Surface Features
Black Ceramic Glass
Features
Technologies
• PowerPlus™ Induction
• SpacePro™ Bridge Element
• Pro-Select® Controls
• SpacePro™ Bridge Element
• Pro-Select® Controls
Clock
No
Digital Display
Yes
Downdraft Ventilation
No
Additional Information
• Cool-to-the-touch cooktop generates heat directly to the pan, so spills can’t burn on
• Adjusts from a powerful boil to a gentle simmer instantly
• Heavy-duty Professional-Grade knobs deliver precise temperature control
• Efficient use of Power
• Cookware Compatible: Induction-friendly stainless steel or iron-based cookware
• Adjusts from a powerful boil to a gentle simmer instantly
• Heavy-duty Professional-Grade knobs deliver precise temperature control
• Efficient use of Power
• Cookware Compatible: Induction-friendly stainless steel or iron-based cookware
Electrical Information
Information
• 240 V
• 60 Hz
• 40 A
• 60 Hz
• 40 A
Certifications and Approvals
ADA Compliant
Yes
Sabbath Mode
No
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
2.87 inch(es) / 7.3 cm
Depth
20.13 inch(es) / 51.12 cm
Additional Dimensions
• Cutout Width (Min.)/(Max.): 33-7/8"/34"
• Cutout Depth (Min.)/(Max.): 19-1/8"/19-1/4"
• Cutout Height: 3-5/8"
• Cutout Depth (Min.)/(Max.): 19-1/8"/19-1/4"
• Cutout Height: 3-5/8"
Shipping Dimensions
Weight
53 lb(s) / 24.04 kg
Warranty
Warranty
Limited 1-Year Parts and Labor
UPC
UPC#
0-57112-99213-6
