Features
CONTINUOUS GRATES
Designed for cooking multiple dishes at varying temperatures on a single cooktop. These grates allow easy movement of even the heaviest pots and pans from burner to burner — without lifting.
SOFT CLOSE DOOR
Gently close the oven door even when your hands are full with the soft close door.
SLEEK DESIGN
Full-framed linear grates, sturdy knobs, premium brass burner accents and the Electrolux signature pinstriped glass lend to the sleek design that make this range a focal point of your kitchen.
ONE HOUR STEAM CLEAN
Keep your oven looking its best with the one hour Steam Clean cycle that's chemical- and odor-free.
TEMPERATURE PROBE
Cook proteins to juicy perfection, never over or undercooked, with an integrated Temperature Probe which alerts you when your food has reached the desired temperature.
TRUE CONVECTION
Conquer even the most challenging recipes with True Convection, which uses three heating elements and a fan for even cooking results.
Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Steam Clean
Cooktop
Burners/Elements
6
Burner/Element Size
• Right Front Burner: 18,000 / 750 BTU Dual
• Right Rear Burner: 12,000 / 750 BTU Dual
• Left Front Burner: 18,000 / 750 BTU Dual
• Left Rear Burner: 12,000 / 750 BTU Dual
• Center Front Burner: 12,000 / 750 BTU Dual
• Center Rear Burner: 12,000 / 750 BTU Dual
• Right Rear Burner: 12,000 / 750 BTU Dual
• Left Front Burner: 18,000 / 750 BTU Dual
• Left Rear Burner: 12,000 / 750 BTU Dual
• Center Front Burner: 12,000 / 750 BTU Dual
• Center Rear Burner: 12,000 / 750 BTU Dual
Burners
Sealed
Oven
Capacity (cu. ft.)
4.4
Number of Ovens
Single
Programs
• Bake
• Bread Proof
• Broil
• Convection Bake
• Convection Roast
• Cook Time
• Keep Warm
• Probe
• Bread Proof
• Broil
• Convection Bake
• Convection Roast
• Cook Time
• Keep Warm
• Probe
Features
Technologies
True Convection
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Wi-Fi
No
Additional Information
• 3 Continuous Cast Iron Grates
• Front Control
• Hidden Bake
• Bake Element: 3,300 Watts
• Broil Element: 3,300 Watts
• Convection Element: 3,380 Watts
• Adjustable Leveling Legs
• LED Display
• Number of Rack Positions: 5
• Extra Large Window
• Oven Light Type: Halogen (2 x 40Watts)
• Front Control
• Hidden Bake
• Bake Element: 3,300 Watts
• Broil Element: 3,300 Watts
• Convection Element: 3,380 Watts
• Adjustable Leveling Legs
• LED Display
• Number of Rack Positions: 5
• Extra Large Window
• Oven Light Type: Halogen (2 x 40Watts)
Electrical Information
Information
• Minimum Circuit Required: 30 Amps
• Voltage Rating: 240 V
• Voltage Rating: 240 V
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Included
• LP Conversion Kit
• Power Cord
• Power Cord
Dimensions
Class Width
36"
Width
29.94 inch(es) / 76.04 cm
Height
35.37 inch(es) / 89.85 cm
Weight
359.99 lb(s) / 163.29 kg
Additional Dimensions
• Maximum Height: 36 5/8"
• Depth: 25 7/8"
• Depth With Door 90° Open: 43 94/100"
• Oven Interior Height: 14 1/2"
• Oven Interior Width: 28 1/4"
• Oven Interior Depth: 16 1/2"
• Depth: 25 7/8"
• Depth With Door 90° Open: 43 94/100"
• Oven Interior Height: 14 1/2"
• Oven Interior Width: 28 1/4"
• Oven Interior Depth: 16 1/2"
Warranty
Warranty
1-Year on parts and labor
