Features
PRECISE TEMPERATURE CONTROL FUNCTION
Create a perfect berry reduction or slow-simmered marinara without scorching with our Precise Temperature Control function. Unlike other induction cooktops, our technology uses a sensor to continuously measure pan temperature and automatically adjusts the heat to ensure your pan maintains the temperature you set from start to finish.
POWER SLIDE
Boil, sear or sauté on the front burner and when you’re finished, simply slide the pan to the back burner and the cooktop will automatically adjust to keep food warm and ready to serve.
BRIDGE FEATURE
Expand your culinary horizons to specialty foods like crepes and paninis with a Bridge Feature that connects two cooking elements for even heat even with larger pans or griddles.
ENERGY EFFICIENT
Use less energy while you cook with energy-efficient induction technology which heats the pan directly for less heat loss.
QUICK AND RESPONSIVE
Induction technology transfers heat directly to your cookware, bypassing the cooking surface which allows the cooktop to respond more quickly to temperature changes for more precise cooking and allows your food to cook faster and your cookware temperature to adjust more quickly than with gas or traditional electric cooktops.
SERVE WARM MODE
Dinner parties are more effortless with Serve Warm Mode which sets all the elements to warm, keeping your dishes at the perfect temperature for family and friends to serve themselves.
AUTOMATIC POT DETECTION
Get cooking with ease with automatic pot detection that lights the controls for the element as soon as you set down your pan.
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Right Front Element: 3,600 Watts
• Left Front Element: 2,600 Watts
• Left Rear Element: 2,600 Watts
• Center Rear Element: 3,600 Watts
• Left Front Element: 2,600 Watts
• Left Rear Element: 2,600 Watts
• Center Rear Element: 3,600 Watts
Burner/Element Size
• Right Front Element: 8"
• Left Front Element: 7"
• Left Rear Element: 7"
• Center Rear Element: 8"
• Left Front Element: 7"
• Left Rear Element: 7"
• Center Rear Element: 8"
Elements
Smoothtop
Features
Additional Information
• Control Location: Front
• Display Interface Color: White
• Display Type: Capacitive Touch
• Auto Pan Detect
• UL Listed
• cUL Listed
• Display Interface Color: White
• Display Type: Capacitive Touch
• Auto Pan Detect
• UL Listed
• cUL Listed
Electrical Information
Information
• Minimum Circuit Required: 30 Amps
• Voltage Rating: 240 V
• Voltage Rating: 240 V
Certifications and Approvals
ADA Compliant
Yes
Dimensions
Class Width
30"
Width
30.63 inch(es) / 77.79 cm
Height
4.37 inch(es) / 11.11 cm
Depth
21.37 inch(es) / 54.29 cm
Weight
50.35 lb(s) / 22.84 kg
Additional Dimensions
• Maximum Cutout Width: 29 7/8"
• Minimum Cutout Width: 28 1/2"
• Minimum Cutout Width: 28 1/2"
Warranty
Warranty
1-Year parts and labor
