Features
CRYSTALDRY™
Patented CrystalDry™ technology transforms moisture into heat up to 176°F to get dishes 60% drier,* so you can put away your plastic dishes immediately into the cupboard when the dishwasher is finished.
*Based on aggregate average drying performance of Bosch Dishwashers with CrystalDry on combined household load including plastics, glass, steel, and porcelain as compared to Bosch Dishwashers with PureDry. Drying performance may vary by dish type.
*Based on aggregate average drying performance of Bosch Dishwashers with CrystalDry on combined household load including plastics, glass, steel, and porcelain as compared to Bosch Dishwashers with PureDry. Drying performance may vary by dish type.
PRECISIONWASH®
With Bosch PrecisionWash®, intelligent sensors continually scan and check the progress of dishes throughout the cycle, and powerful, precision spray arms go to work targeting every item of every load.
42 DBA
A range of technologies makes Bosch the quietest dishwasher brand in the U.S.* with impressively low decibel levels. For you, that means never having to wait until going to bed to run the dishwasher.
*Based on an average of sound ratings of 24" Full Size Stainless Steel Tub dishwashers contained in major brands websites. Major brands defined as TraQline Top 5 Market Share December 2024.
*Based on an average of sound ratings of 24" Full Size Stainless Steel Tub dishwashers contained in major brands websites. Major brands defined as TraQline Top 5 Market Share December 2024.
FLEXIBLE 3RD RACK
The Flexible 3rd Rack has expandable wings that easily lower to accommodate more of your deeper items. Meanwhile, adjustable tines let you customize the rack’s loading space to fit awkward or bulky utensils.
24/7 AQUASTOP®
The 24/7 AquaStop® system contains leaks through a precisely engineered tub and a solid molded base. Sensors detect leaks and pump out water, even when the system is off. So you never have to worry about leaks whether you're at home or away.
CONTROL OVER YOUR DISHWASHER WHEREVER YOU ARE, WHENEVER YOU WANT
Remote Control is designed to bring your life more freedom and comfort. You can easily do all the controls that can be done on dishwasher via HC app, such as start/pause your dishwasher remotely, select programs and options, set timings and edit dishwasher settings via Home Connect app wherever and whenever you want.
REMOTELY MONITOR YOUR DISHWASHER WHENEVER YOU ARE, WHENEVER YOU WANT
With Remote Monitoring, you can monitor all type of real-time information related with your connected dishwasher. You can easily check program status such as remaining cycle time or the details as salt/rinse aid level, water hardness level and be sure everything is running smoothly.
YOUR FAVOURITE PROGRAMME WITH JUST ONE TOUCH
Make the most out of your connected dishwasher by simplifying your daily life. With the Favourite programme you can simply set up your most used programs and options as your favourite combination. The programmed setting can be started via the Home Connect app or directly on the display with one step. Combine for example the Extra Dry option to the Eco 50° Program and start the dishwasher with only one touch. Personalized settings that get your dishes done by just one touch.
EASY START GUIDE
Selecting the right wash programme for your dishwasher can not only be confusing, but can often result in less than perfect cleaning results. Home Connect with Easy Start Guide function takes the guesswork out of this job and always recommends the right program to you -directly from your mobile device. Every time. And with every wash. The only thing you need to do is enter the degree of soiling and the type and quantity of the dishes or cutlery being washed in your Home Connect app. So you can easily choose the right program and get perfect results, cycle after cycle.
EXTRA SILENT FOR WHENEVER YOU NEED IT
Sometimes you need a extra silent environment at home to focus on your daily chores. The Silence On Demand function can be activated per Home Connect App and silences your dishwasher whenever necessary. It reduces noise to a minimum for up to 30 minutes at any time by an active pause while the dishwasher keeps on running. With the Silence on demand function you can focus on what matters most.
Specifications
General
Series Name
800 Series
Type
Built-In
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Place Settings
15
Tub Material
Stainless Steel
Silence Rating
42 dB
Cycle Information
Number of Cycles
5
Wash Cycles
• Heavy
• Auto
• Normal
• Speed60 (1 hr Wash)
• Favorite
Additional wash cycles (in Home Connect®):
• Rinse
• MachineCare
• Delicate
• Auto
• Normal
• Speed60 (1 hr Wash)
• Favorite
Additional wash cycles (in Home Connect®):
• Rinse
• MachineCare
• Delicate
Options
• Sanitize
• Remote Start
• Crystal Dry
• PowerControl Options
Additional options (in Home Connect®):
• Half Load
• Eco
• Remote Start
• Crystal Dry
• PowerControl Options
Additional options (in Home Connect®):
• Half Load
• Eco
Features
3rd Rack System
Yes
Control Lock
Yes
Silverware Basket
Yes
Wi-Fi
Yes
Additional Information
• Wash system: PrecisionWash® with PowerControl®
• Drying system: CrystalDry™
• Rack adjustability: RackMatic®
• Concealed water heating element
• Leak protection system: 24/7 AquaStop® Plus
• Home Connect® (Wi-Fi enabled)
• NSF®-certified** sanitize option: No
• Water softener
• Five-level wash
• Anti-Fingerprint Finish: No
• Special features: CrystalDry™ Option, InfoLight®
• Adjustable feet
• Water usage per cycle: 2.6 gal
• Drying system: CrystalDry™
• Rack adjustability: RackMatic®
• Concealed water heating element
• Leak protection system: 24/7 AquaStop® Plus
• Home Connect® (Wi-Fi enabled)
• NSF®-certified** sanitize option: No
• Water softener
• Five-level wash
• Anti-Fingerprint Finish: No
• Special features: CrystalDry™ Option, InfoLight®
• Adjustable feet
• Water usage per cycle: 2.6 gal
Electrical Information
Information
• ENERGY STAR® Certified
• Total annual energy consumption: 240 kWh
• Watts: 1440 W
• Current: 12 Amps
• Volts: 120 V
• Frequency: 60 Hz
• Power cord full length: 67"
• Power cord install length from edge of unit when facing the door: Left – 47 1/4", Right – 47 1/4"
• Minimum water pressure: 7.25 lb/sin
• Length outlet hose: 74 3/4"
• Total annual energy consumption: 240 kWh
• Watts: 1440 W
• Current: 12 Amps
• Volts: 120 V
• Frequency: 60 Hz
• Power cord full length: 67"
• Power cord install length from edge of unit when facing the door: Left – 47 1/4", Right – 47 1/4"
• Minimum water pressure: 7.25 lb/sin
• Length outlet hose: 74 3/4"
Certifications and Approvals
Energy Star Certified
Yes
Accessories
Optional
• Junction Box: SMZPCJB1UC
• Drain Hose Extension Kit: SGZ1010UC
• Edge Protector + Power Cord Clip Install Kit: SMZEPCC1UC
• Drain Hose Extension Kit: SGZ1010UC
• Edge Protector + Power Cord Clip Install Kit: SMZEPCC1UC
Dimensions
Class Width
24"
Width
23.56 inch(es) / 59.85 cm
Weight
116.01 lb(s) / 52.62 kg
Additional Dimensions
• Overall: 34 1/16"H x 22 9/16"D
• Required cutout size (HxWxD): 34 1/8" x 24" x 24"
• Required cutout size (HxWxD): 34 1/8" x 24" x 24"
