Specifications
General
Color
Panel Ready
Tub Material
Stainless Steel
Maximum Speed
1800 rpm
Capacity
Total Capacity IEC
2.44 cu. ft.
IEC (By Class)
3 cu.ft. and below
Cycle Information
Number of Cycles
13
Wash Cycles
Programs : Auto wash, Stain care, Time choice, Sani, White, Color, Quick, Everyday wear, PermaPress, Wool;
Delicate, Rinse and Spin & Drain;
Options : Prewash (2hr), Anti-crease (2hr), High water level, Super rinse (up to 7 rinses), Delay Start (24 hrs), Spin speeds 400-1800 RPM speed, No spin/no drain and Temperatures from cold to 205ºF.
Features
Control Lock
Yes
Stackable
Yes
Steam Cycle
No
Reversible Door
Yes
Dispensers
Detergent.
Additional Information
Technology : Line Series™ Style control with LCD full graphic display, Internal heater produces optimal temperatures during main wash, Automatic load balancing, Electronic automatic door latch and Thermistor electronic thermostat ensures accurate wash temperatures within 1½ºF;
Construction : ActiveDrum™, Quattro-suspension system, SmartSeal-solid rubber door gasket, Stainless Steel inner/outer drum, Heavy duty induction motor, Galvanized steel base, Cast iron rear flywheel, ISO9001 certified for quality standards and noise level 41 dB(A) wash / 70 dB(A) spin;
SIMPLICITY/COMFORT : LCD full graphic display, Complies with ADA (American Disability Act) accessibility guidelines, Countdown time display, Program memory, End of program signal, Auto door opening, Remaining time indicator, 24" width exterior cabinet for more convenient & flexible installations, and Swing-out detergent dispenser;
6 fold Aqua Block System and Child-safe start option;
Panel sold separately.
Electrical Information
Information
220
Certifications and Approvals
Energy Star Certified
Yes
Dimensions
Class Width
25" And Under
Width
23.5 inch(es) / 59.7 cm
Height
33.5 inch(es) / 85.09 cm
Depth
23.13 inch(es) / 58.74 cm
Weight
172 lb(s) / 78.02 kg
Additional Dimensions
Depth w/door open : 47 7/8";
Height (inches) : 33 1/2" to 34 1/2";
Platform increases the height of a single unit by 12 3/8" to 14 7/8". Has four adjustable feet. Available in White, Black and Titanium.
Height 12 3/8" to 14 7/8";
Width 23 7/16";
Depth 21 1/4".
Warranty
Warranty
2 Years Limited Warranty on Parts and Labor
